RK F 320 / 3 Colour Flexo Rotary Label Printing Machine With IR Lamp Hot Air System

The RK F 320 / 3 Colour is a compact tower type flexographic press with three stacked printing units, drying between each colour, and two rotary die-cutting units at the delivery end. Each printing unit uses a ceramic anilox roller with an individual motorized anilox system, 360° unit regulation and a dial gauge for registration. A 3 HP AC variable speed main drive runs the line.

What sets it apart from the 5 and 6 colour versions is the delivery: instead of only rewinding finished label rolls, it can also sheet-cut the printed web and deliver sheets on a short conveyor. That makes it useful for tags, sheet-fed labels and cut blanks as well as roll labels.

Three Colour Flexo Printing in a Low-Height Tower

Three stacked printing units cover logo, text and one or two spot colours. At 5.5 ft high, the tower fits under a normal factory ceiling.

IR Lamp Hot Air Dryers on All Units

Each unit has an IR lamp based hot air dryer, with an individual dryer window so the operator can check drying at each colour. A UV dryer is available as an extra option.

Two Rotary Die-Cutting Units With Short Conveyor

The first rotary unit cuts the label shape; the second sheet-cuts, with a short conveyor belt drive system carrying the sheets out. Roll labels and sheet output from one machine.

Lamination Unit

A lamination unit applies a protective or gloss laminate inline for labels that need durability.

Ultrasonic Web Guide and Electronic Tension Control

The unwinding unit carries an imported ultrasonic electronic web guide, a splicing table and paper holder for paper joining, and an imported auto electronic tension controller. The rewinding unit uses a tension controller with mechanical clutch system.

Low Power Consumption

The whole machine draws 5.5 HP on 3 phase, with a 3 HP main motor – a real saving on running cost for a press that runs all day.

The label roll (up to 600 mm diameter) is loaded on the unwinding unit, centred by the ultrasonic web guide and held at a steady tension by the electronic tension controller.

The web passes through the three printing units. At each unit a ceramic anilox roller meters ink onto the plate, the plate prints the image, and the web passes through that unit's IR hot air dryer before the next colour. The lamination unit applies laminate after the last colour where the job needs it.

The web then enters the two rotary die-cutting units. The first cuts the label shape for roll output, which winds on the rewinding unit (up to 450 mm diameter). For sheet jobs, the second unit sheet-cuts the web and the short conveyor carries the sheets out. Speed is set on the variable speed drive and registration is trimmed with the dial gauges at each unit.

Barcode, MRP and batch labels

one to three colour labels in high volume.

Logo and brand labels

spot colour logo with text.

Carton and shipping labels

simple, durable identification labels.

Sheet-cut labels and tags

delivered as sheets on the conveyor.

Laminated labels

using the inline lamination unit.

In-house label printing

for manufacturers who want a low-cost, low-power press in limited space.

The RK F 320 runs the self-adhesive label stock and paper, within a 320 mm paper width. Anilox rollers and printing cylinders are supplied to your requirement, so share your actual materials and artwork with RK before the specification is fixed.

• Vertical Tower Machine (RK F 320 series)the category overview.
• RK F-320 5 Colour With IR Lamp With Hot Air Systemfive colours with UV dryer and turn bar.
• RK F-320 1 Colour With IR Lamp With Hot Air Systemsingle colour with online slitting and dual rewinding.
• Micro Flexocompact two-colour printing and die cutting with 220 mm feeding width.

RK Label Printing Machinery Pvt. Ltd. has manufactured label printing and converting machinery in Ahmedabad, Gujarat since 1995, operates three manufacturing units and supplies customers in 23+ countries. The RK F 320 tower series is offered in 1, 3, 5 and 6 colour versions so a printer buys the colour count the jobs need, and every machine is configured to the customer's drying, finishing and options rather than sold as a fixed model.

• Is three colours enough? If your regular labels are logo, text and one spot colour, yes. If you print process artwork, look at the 5 or 6 colour versions.
• Roll or sheet output? The two die-cutting units give both; confirm which your customers need.
• Drying: IR hot air is standard; add the UV dryer option if you run UV inks or varnish.
• Label sizes: 310 mm print width and 430 mm print length – check your layouts.
• Space and power: 5.5 ft high, 5 ft wide, 12 ft long; 5.5 HP 3 phase.
• Output: 50 m/min published; calculate labels per shift from your label repeat.

The price of a 3 colour tower type flexo label printing machine depends on the die-cutting and conveyor arrangement, lamination, UV option, anilox and cylinder sets. Prices are quoted ex-works Ahmedabad with GST at 18% applicable; engineer transport and stay for installation and training at your site are borne by the customer. Share your label materials, sizes, colour count and monthly volume with RK and the engineering team will recommend a configuration and quote against it.
